Spice Extraction: Getting the most out of Spices.
Why Spices?
Herbs and spices are very powerful ingredients for cooking or even health. They also provide powerful health benefits like antioxidants, vitamins, and health compounds.
As consumer preference shifts towards products with natural ingredients and organic flavors, spice extraction will become a viable solution to meet the increasing demand for spices across the food and beverage, pharmaceutical, nutraceutical, and personal care industries.
The Extraction Advantage
Oleoresins are concentrated natural extracts with active compounds from plants, spices and herbs. These are 5-20 times stronger in flavor than their corresponding spices. During their extraction, fewer low flavor notes are destroyed as opposed to during steam distillation of essential oils.
Moreover, oleoresin oils contain some important flavor notes which are absent in volatile oils. For instance, while black pepper oil contains just the top black pepper notes, its oleoresin contains piperine and other low flavor notes, making it a more effective flavoring agent. Oleoresins are used at 0.1-0.5% in finished products.
Consequently, food and spices companies are inclining towards oleoresin production, thus heightening market growth prospects in the forthcoming decade's forecast period.
Requirements in Extraction
- Lower adulteration in extraction process.
- The extracted solvent should have higher bioactive and lower residues.
- The output should be chemical free.
- Multiple recipe selection.
- Clean, safe and Green Technology.
- Robust process and monitor controlling.
- Operational safety.
- Minimal human intervention.
System Features
Accurate Pressure
Control
Consistent Flow
Control
Superior Sealing
Technology
Unique Extractor
Closure Design
Special Separator
Design
Proprietary Changeover
Valves
Bringing the Future of Extraction to the World
Our team starts by blending principles with practicalities and continue by connecting proven automation process blocks into a holistic solution.
-
Integration:
Combining scientific and engineering principles with a rich and
diversified practical experience to provide innovative solutions
to challenges.
-
Modularity:
Automation based on proven process blocks.
-
Connectivity:
Linking equipment and control systems via PCs and PLCs for
seamless operation.
System Specifications
| Parameters | Level 1 | Level 2 | Level 3 |
|---|---|---|---|
| Single Extractor Volume (Litre) | 5 | 25 | 100 / 200 / 300 |
| No. of Extractors | 2 or 3 | 2 or 3 | 2 or 3 |
| Extractors Usage | Single | Single or Series | Single or Series |
| Pressure Bar (PSI) |
350 - 650 (5000 - 9500) |
350 - 650 (5000 - 9500) |
350 - 650 (5000 - 9500) |
| Temperature — °C (°F) |
70 - 110 (158 - 230 |
70 - 110 (158 - 230 |
70 - 110 (158 - 230 |
| CO2 Recirculation | Yes | Yes | Yes |
| Extractor Changeover Valves | Automatic | Automatic | Automatic |
| CO2 Pump Flowrate (LPH) | 40-80 | 150 - 350 | 600 - 3000 |
| Co-Solvent Pump | Yes | Yes | Yes |
| CO2 Feeding & Recovery System | Included | Included | Included |
| Available Certifications |
CE / U / U2 cGMP / ASME BPE / UL / SIL-3 |
CE / U / U2 cGMP / ASME BPE / UL / SIL-3 |
CE / U / U2 cGMP / ASME BPE / UL / SIL-3 |
| Area Required* (m/ft) |
4.88 x 1.37 x 2.44 / 16 x 4.5 x 8 |
8 x 2.8 x 5.6 / 26 x 27 x 18.5 |
8 x 2.8 x 5.6 / 26 x 27 x 18.5 |
| * All systems can be customized based on the factory layout | |||
Recent Projects
Pilot Scale Extraction System
- Research for Herbal products Extraction
- Capacity: 20L
- Pressure Rating: 650 bar
- Industry: Herbal Pharma Products
- Location: India
Production Scale Extraction System
- Essential Oil Extraction Plant
- Capacity: 300L
- Pressure Rating: 350 bar
- Industry: Essential Oil
- Location: Indonesia
Experience CO2 Extraction
for your Biomass
Discover compounds from your biomass to accelerate
product innovation for your business and experience
CO2 extraction at its finest.
